Cresto Safety

Cresto Energy Pro 1136

Harness 1136

Product number: 1072

The focus of the harness design is on ergonomics and comfort. All in order for the user to be able to perform their work as efficiently and safely as possible.

Great comfort and ergonomics

H-Design

Loops for tool bags and accessories

Standards
EN 358 : 2018
EN 813 : 2008
EN 361 : 2002

Quantity:

Find reseller

Product description

This harness is developed with and for people within industrial tower and pole climbing industry. Design, ergonomics and comfort are the key elements of this robust harness. The H-design makes it easy to put on and remove and its great support and equipment functions come in handy when working long days with a need for great flexibility and comfort.

The harness is equipped with tool holders for bags and accessories. On the back of the support belt there is a perfect place for attachment of a personal evacuation device e.g. Smartline X.

Items

Reference
Article name
Size
Colors
GTIN
Country of origin
012200476 Cresto, Energy Pro, XS XS BLACK/GREY 7350015797055 Slovakia
012200471 Cresto, Energy Pro, S S BLACK/GREY 7350015796324 Slovakia
012200472 Cresto, Energy Pro, M M BLACK/GREY 7350015796331 Slovakia
012200473 Cresto, Energy Pro, L L BLACK/GREY 7350015796348 Slovakia
012200474 Cresto, Energy Pro, XL XL BLACK/GREY 7350015796355 Slovakia
012200486 Cresto, Energy Pro, S, hi-vis yellow S HIVIZYELLOW 7350015796454 Slovakia
012200487 Cresto, Energy Pro, M, hi-vis yellow M HIVIZYELLOW 7350015796461 Slovakia
012200488 Cresto, Energy Pro, L, hi-vis yellow L HIVIZYELLOW 7350015796478 Slovakia
012200489 Cresto, Energy Pro, XL, hi-vis yellow XL HIVIZYELLOW 7350015796485 Slovakia
012200483 Cresto, Energy Pro, XL, hi-vis orange XL HIVIZORANGE 7350015796539 Slovakia

Technical data

Product properties
Brand: Cresto
Material: Polyester Nordguard ™
Min/Max load (kg): 30 / 141
Maximum number of users: 1
Min/Max working temperature (c): - 40 / 100
EN-standard: EN 358 : 2018, EN 813 : 2008, EN 361 : 2002
Notified body: 1019, VVUU, a.S., Pikartska 1337/7 716 07 Ostrava - Radvanice Czech Republic
Annual inspection: Yes, every 12 months
Life span: 10 + 2 years. Product lifecycle 10 years + 2 years stock keeping
RFID: Yes
Warranty: 2+1 year when registered in Inspector
Declaration of Conformity: Yes
Minimum breaking strength - MBS (kN): 15
Chest buckles: Aluminium alloy, with stainless steel components and brass release clips. Strength: >18kN
Leg buckles: Aluminium alloy, with stainless steel components and brass release clips. Strength: >18kN
Front A-point: Textile angled loop: >15kN
Back A-point: Galvanized steel 45 mm> 30kN
Side D-rings: Galvanized steel 70mm: >30kN
Back adjuster: Heat treted steel saltspray tested 74 hours > 18 kN
Adjustable under load: Yes
Padding material: Shoulder and leg padding: Breathable 3-D mesh Waist belt padding: Ergo+ Honeycomb, breathable
